STB BlackMagic 3D
The BlackMagic 3D was the STB-branded version of the 3dfx Voodoo2 3D accelerator card, released just after 3dfx had acquired STB Systems.
 |
Released | 1999 |
| Bus | PCI | |
| Chipset | 3dfx Voodoo2 | |
| Standards | Hercules, CGA, EGA, VGA | |
| Memory | 12 MB EDO DRAM | |
| RAMDAC | - | |
| Ports | 15-pin DSUB (analogue video out) and 15-pin DSUB (passthrough to 2D VGA card) | |
| Part # | 1X0-0649-308, 1X0-0782-006 | |
| FCC ID | - | |
| Price | - | |
| See Also |
The BlackMagic 3D featured 12 MB of EDO DRAM, split between 4 MB for the 2D frame buffer and 8 MB for 3D textures. It supported 3D resolutions up to 800 x 600.
Board Revisions
I don't have any information on board revisions for the BlackMagic 3D cards.
Competition
In the Media
Setting it Up
I have no information on setting up the BlackMagic 3D.
Downloads
Spec Sheet The original spec sheet from STB Systems in 1999. |
Original Utility Disk Get in touch if you can provide this missing item! |
ROM BIOS Get in touch if you can provide this missing item! |
Windows 9x Drivers |
|
More Pictures
